SKU AGT-H15R

1 ton, 13.5HP RATO Mini Excavator w/ pilot control system | AGT-H15R

Sale Sale
Original price $6,899.00
Original price $6,899.00 - Original price $6,899.00
Original price $6,899.00
Current price $5,719.00
$5,719.00 - $5,719.00
Current price $5,719.00

The AGT-H15R Mini Excavator is perfect for small to medium-sized projects, offering a compact 1-ton design and a maximum digging depth of 5.41 feet. Ideal for tight spaces like gardens, parks, and orchards, it combines maneuverability with enhanced safety features, including internal hydraulic hoses and rear-opening compartments for easy maintenance.

In Action Video

Manual

Technical Data:

  • Operation Weight: 1 Ton
  • Engine: RATO Gasoline
  • Horse Power: 13.5
  • Max Angle: 35 Degree

Specific Data:

  • Bucket Capacity: 0.88 cubic feet
  • Fuel Grade: 92#
  • Fuel Type: Gasoline
  • Engine Oil Change: 1.1 quarts
  • Fuel Consumption: 0.5-1.2 quarts/hour
  • Traveling Speed: 0-1.24 mph

Hydraulic System:

  • Pressure (Travel/Slewing): 23.5/18 psi
  • Motor Types: BM6K-315 (Travel), BM2-315 (Slewing)
  • Tank Capacity: Fuel - 1.77 gallons, Hydraulic Oil - 4.76 gallons
  • Main Pump Flow Rate: 8-12 gallons/minute

Operating Parameters:

  • Max Digging Height: 102.76 inches
  • Max Unloading Height: 72.83 inches
  • Max Digging Depth: 65 inches
  • Max Digging Radius: 112.2 inches
  • Overall Length: 84.25 inches
  • Overall Width: 39.37 inches

Customer Reviews

Based on 11 review
55%
(6)
45%
(5)
0%
(0)
0%
(0)
0%
(0)
B
Barney Bedwell
AGT15R

This machine is very capable for its small size.
I have been very impressed with the power and performance.

M
Mark Washington
The Best Customer Service!!!

The H15R mini excavator was as I expected from watching plenty of YouTube. What I didn’t expect was the excellent customer service. My machine had an unexpected and serious issue. When I found this problem I immediately contacted AGT and they had a tech at my house in 4 days. I’m 5hrs from their Chicago warehouse and their tech drove here with all the right tools and all the right knowledge. I major repair was made in less than an hour.
I had a great sales experience, a great pickup experience and the best repair service. Highly recommend purchasing from AGT Industrial.

T
Terry B.

My machine was supposed to ship from Chicago but it appears that they were out, so it shipped from LA. It took a little longer than the site listed but understandable since I ordered it a few days before Christmas, so with Christmas and new years holiday it took a little longer. It did arrive a day earlier than the sugges

K
Kevin Real
Decent for price, but not without some issue.

Showed up and throttle control handle broken off, called customer service. No pickup, left voicemail, no reply after a couple days now, not the end of the world, $25 part, just annoying. Fuel shut off left on from factory, engine flooded. When I started it, shiot all the fuel out exhaust. Only ran for a few seconds which is good because there’s no oil in engine. No indication that oil was drained. I don’t suspect leak because there’s no oil all over machine. Couple scuffs in paint from shipping, not AGTs fault. Digger arm a little crooked (about 2° out of plumb). Hour meter not hooked up, probably from jostling during shipping. Thumb kit includes no direction, but reasonably self explanatory except for 3 way diverting valves. Assume they don’t get used, and the lack of adapters for connecting to H15, but there’s a note on ordering screen that states as such, fittings about $8 plus shipping online Also, thumb kit short (1) M25x100 bolt for affixing upper arm included in kit, so find another or get some spacers to make up slop. Rear engine cover panel one of the bolts was stripped out, so I’ll have to replace that. Track control arms bent at slightly different angles so they don’t line up, quite a bit of play in them so I plan on devising some method of stiffening them up, as well as the foot pedals.

All in all for a sub $6k machine it’s not bad, I’m sure more things will come up once I actually get to use it, as it is still in the shipping pallet, but I’m sure nothing anybody with a reasonable amount of mechanical inclination can’t overcome. FYI, the Majic brand Caterpillar Yellow from tractor supply near identical match to paint (if your machine is yellow).

s
steve rider

Good product
